Windsor W 800 - 5650

Manufacturer: Windsor Type of machine:W 800 - 5650 Year:1990 Delivery time:Immediately Terms of Delivery:Ex - Works Location:Eschweiler - Germany Controlversion:WMT Screen text:German Price:on request Technical details Clamping unit Clamping force:8000 kN Mould opening force, max.:490 kN Size of mould platens (h x v):1400 mm x 1300 mm Distance between tie bars (h x v):1000 mm x 900 mm Mould opening stroke:1000 mm Mould height min.:700 mm Max daylight:1700 mm Hydraulic ejector - stroke:200 mm Ejector force forward/backward:150 kN Injection unit Screw diameter:100 mm Ls/D ratio:20 Injection pressure:1800 bar Stroke volume:3140 ccm Shot weight, PS:2660 g Injection stroke:400 mm Screw speed:138 1/min Plasticising rate max.:767 g/s Nozzle pressure:185 kN Electric and Hydraulic Equipment Nominal capacity of pump motor:90 kW Installed heating capacity:53 kW Adjustable barrel heating zones:6 Reservoir capacity:3500 ltr. Dimensions und weights Dimensions of the machine ca.:11,2 m x 3,015 m x 2,77 m Total machine weight:39000 kg Dimension clamping unit:4,96 m x 2,50 m x 2,70 m Clamping unit - weight:28000 kg Dimension injection unit:5,15 m x 2,70 m x 2,29 m Injection unit - weight:11000 kg Accessories - anti vibration pads - hopper - Unirob Robot system Additional information - Robot interface - 3x Core pulls - 3x Air valves - shut off Nozzle - 2x 10-zones water flow
