Bihler HUMMINGBIRD HB 80 High speed press

Bihler HUMMINGBIRD HB 80 High speed press High speed press with composite tool for manufacture of contact parts including welding and tapping. Composite tool for manufacture of contact parts. System includes Bihler-control and Bihler-NC-units D2 K, D1E for contact welding and GSE K2 for tapping. EASY CONTROL- Press unit EC-P Stand-alone press control unit for Minster presses P2H, E2H, HB 80 process-modules GSE K Tapping unit for utilization on press units - Threads from M2 to M20 with 3 motor variants - quick change of thread formers and thread size - no use of pitch leaders - torque monitoring - monitoring of depth of the thread as well as recognition of breaking - high cycle speeds - low mounting height NC D2K Technical Data Cutoff method: Material: Material dimensions profiled strip material: Production speed: cutoff blade profiled strip material width: - 5mmthickness: - 1,7mmlength: - 4,5mm up to 300/min NC D1E Technical data Cutoff method: Material: Material dimensions wire: profiled strip material: Production speed: electrode cutoff wire and profiled strip material ø: 0,2 - 2mmlength: - 3,0mm width: - 3mmthickness: - 0,8mmlength: - 3mm up to 400/min
