BRIQUETTING MACHINE COMPACT SYSTEM GIGANT 220

Description:

Throughput* 80-210 kg/h Briquette Ø 80 mm Motor power 15 HP Ø main cylinder 180 mm Oil storage tank 180 Lt Oil pump 59 Lt/min Shaves container 1200x1200 mm Profundity 2100 mm Weidth 1350 mm Height 1600 mm Weight 1450 kg The Compact System briquetting presses are equipped with a large shaves container, which is optimally qualified for automatic charging from the filtering aspiration plant because of its rectangular form. The briquetting machines are easy to operate with SPS control system and digital display. The standard filling sensor allows an automatic production process without trouble because of the automatic start/stop system. The Compact System briquetting presses have a large hydraulic filler cylinder which compresses the material at high pressure into a highest density briquette.
